Eotech VUDU 1-8x24MM Scope

  • Sale
  • $1,339.00
  • Regular price $1,409.00
Shipping calculated at checkout.


DIAL UP THE MAGNIFICATION. DOMINATE WITH SPEED.

Technical Specifications

Overview

Like other Vudu scopes, the 1–8X24 SFP features aircraftgrade aluminum construction and bright XC High-Density glass, surgically precise turrets, and intuitive push-button reticle illumination controls. The HC3 quad-level BDC reticle features a precise 0.5-MOA illuminated center dot and 2-, 5-, 8.5- and 12.5-MOA subtensions on the vertical axis (at 8X power). The scope’s field of view at 100 yards is 105.8 feet at 1X and 13.2 feet at 8X..


Included in the box:

  • Vudu® 1-8X24 Rifle Scope
  • Operator Manual
  • Reticle Manual
  • Throw Lever
  • Lens Cleaning Cloth
  • Battery



Second Focal Plane

Overall Length


10.9" (278 mm)

Weight


20.8 oz (589.7 g)

Magnification


1-8X

Tube Diameter


30 mm

Objective Diameter


24 mm

Power Source


CR2032

Eye Relief


1X: 3.46-4.09" (88-104 mm)

8X: 3.54-3.9" (90-99 mm)

Field-of-View @ 100 Yards


1X: 105.8 ft (32.2 m)

8X: 13.2 ft (4 m)

Country of Origin


Made in Japan





Features

Aircraft Grade

Aircraft-grade aluminum, single-piece construction with anodized finish for extreme durability. Laser-etched adjustment indicators and push-button illumination controls for tracking east. Water-resistant, fog-resistant, shock-resistant with single construction eyepiece.

Fog Resistant

Nitrogen gas purging prevents internal fogging over the operating temperature range.

Shock Resistant

The rugged design prevents damage from heavy recoil and rough handling.

Water Resistant

The single-piece tube and o-ring seals prevents moisture and dust from entering the scope even in the harshest environments.

Anti-Reflective Lenses

XC™ high-density, low dispersion glass with anti reflective coated lenses provides efficient light transmission and unmatched edge-to-edge clarity. Water-resistant, fog-resistant, shock-resistant with single construction eyepiece.



Reticle Specifications

Vudu HC3 Reticle

The HC3 is a second focal plane MOA-based hashmark reticle that was designed specifically for the 3-gun competition shooter. The quadplex BDC reticle features a precise 0.5 MOA daylight-visible illuminated center dot and four sub-tension hash marks providing precise ballistic holdovers for those longer shots. The HC3 reticle is also an excellent choice for shooters interested in a short to mid-range low power variable hunting optic.

Adjustment Graduation Per Click


0.25 MOA

Adjustment Graduation Per Rotation


20 MOA

Total Elevation Travel


100 MOA

Total Windage Travel


80 MOA
